T-350DM Desktop Digital Mixer Amplifier with MP3/Tuner/Bluetooth (Phoenix Mic Input)

Description

. Desktop design, exquisite SMT process design.
. Support mp3/TUNER/Bluetooth remote control function, with remote control remote and the control distance can up to 8 meters.
. It has USB interface and SD card interface, integrated MP3 player module, with automatic priority playing audio function, digital screen can display the currently playing track of USB.
. Integrated Bluetooth module to support music playback via Bluetooth of the mobile phone.
. Integrated TUNER module with FM radio antenna port.
. 1 channel EMC input, 2 channel AUX input, 4 channel MIC input.
. Channel priority function EMC>SIREN>CHIME>MIC1>MIC2, MIC3, AUX1, AUX2.
. Each input has independent volume adjustment, and the total volume has treble, bass adjustment and volume control function.
. MIC1-4 balanced input, built-in 48 V phantom power supply.
. Built-in bell and alarm audio source, can remotely controlling trigger.
. Built-in control function of muting background music.
. The device has good self-protections such as short circuit, overload and overheating.
. Two output modes: constant voltage output 100V, constant resistance output 4-16Ω.
. The high-efficiency energy-saving switching power supply is perfectly combined with the high-energy saving and ultra-stable design of class D digital power amplifier.
. Wide voltage supply: 180V-240V can work normally.

Model:T-350DM
Output Interface:4-16Ω, 100V
Output Power:350W
Input Sensitivity & Impedance;
MIC1, 2, 3, 4 input: 5mV/600Ω unbalanced European connection
interface;
AUX1, 2 input: 350mV/10KΩ unbalanced RCA connection interface;
EMC input: 775mV/10KΩ unbalanced European connection interface
Output Sensitivity & Source Impedance: MIX OUT; 1000mV/470Ω unbalanced RCA connection interface
Tone:Bass; 10dB at 100Hz; Treble: 10dB at 10KHz
Frequency Response:50Hz~16KHz(+1dB,-3dB)
Signal to Noise Ratio: MIC1, 2, 3:66dB; AUX1, 2:80dB
Distortion: Less than 0.5%(at 1KHz, 1/3 of rated power)
Mute Function: MIC 1 is prior to mic2-4, aux1-2 audio input,
and EMC is prior to all audio input
Channel Crosstalk:≥50dB
Heat Dissipation: Side in and back out forced fan cooling, starting the fan when turned on, infinitely variable speed processing
Protection: Overheat protection, overcurrent protection, short circuit protection
Power Supply: AC ~220-240V /50Hz
Power Consumption: 500W
Dimension: 324×270×88mm
Weight: 5.4Kg
