SP-S01 Laser Slide Printer

Description

1. Using laser direct marking technology, laser directly burn out the characters.
2. Printing supplies such as ribbon and ink cartridges are not required.
3. It can print all kinds of paint slides, and there is no strict requirement for the smoothness of the
glass paint surface.
4. High printing precision, printed two-dimensional code can be easily scanned.
5. Can realize the printing information export and batch printing function, can also realize the
independent manual input information printing function.
6. No less than 100 slides can be loaded at one time.
7. The mechanical push hand will push the printed slide directly to the slide collection station to
avoid free sliding or falling of the printed slide.
8. Fixed slide collection station without movable slide collection trough.
9. The slide collection station can collect and print at least 40 slides at a time.
10.The printed slide is pushed out horizontally, and the print is located on the right side of the
marking machine.
11. The printed slide collection adopts a stack structure, with the first printed slide at the top of the
stack.
12. The width of the whole machine is not more than 21cm, which can be placed on the slicing
workbench.
13. Printing speed ≤6 seconds/slide, that is, no less than 10 slides can be continuously printed per
minute.
14. Built-in air filtration system, effectively filter printing dust.
15. Adopt the windows system.
16. Built-in color touch screen.
17. Slide loading rack adopts pluggable design to facilitate slide loading
18. The slide uploading slot is located on the right side of the slide marking machine for easy
loading of slides
19. With USB interface, easy to import and export data.
20. Integrated two-dimensional code scanner.
21.The printing parameters of each marking machine are built in the U disk, and you can replace
the computer without calibrating the printing parameters.
22. Use RJ45 interface.
23. The printing software has a variety of automatic selection of printing templates, which can
automatically select printing templates according to different organizations.
24. Optional independent slide collector. The collector can be freely combined and separated from
the marking unit.
25. The glass collection station plus the collector can collect not less than 200 slides at one time.
26.The marking range is 50m X 50mm, the resolution is 2500DPI,
27.the ultraviolet life span is about 3 years, and the ultraviolet power is 1 watt
28.Recommended service life: 8 years

Laser Slide Printer Configuration list:
1, a host
2, a power cord
3, a USB data cable
4. Built-in QR code scanner
5, glass 2 boxes (50 pieces/box)
6, slide upload rack 2
7. A user manual
Net Weight: 21.2kg
Dimensions: 490*200*375mm

Package Info:
Each instrument packed in carton
Gross Weight: 28.2kg
Dimensions: 630*575*600mm
